Super B · Nomada Modular Series
Nomada 12V 105Ah
Modular 105 Ah lithium iron phosphate system battery for scalable onboard energy storage.
Ask our team about compatibility, current pricing and availability.
Ask about this product on WhatsApp ↗
View documentation 6 files & links ↓Key features
- Compact modular battery format
- Designed for integration into a managed battery system
- System design and protection must follow the Nomada installation manual
Specifications
| Nominal capacity | 105 Ah |
|---|---|
| Nominal voltage | 12.8 V |
| Energy | 1344 Wh |
| Chemistry | LiFePO₄ |
| Dimensions (L × W × H) | 437 × 90 × 175 mm |
| Weight | 10 kg |
| Charge method | CCCV |
| Charge voltage | 14.3–14.6 V |
| Maximum charge current | 105 A — observe the datasheet temperature limits |
| Continuous discharge current | 105 A |
| Pulse discharge current | 315 A (30 seconds) |
| Ingress protection | IP66 |
| EAN | 8718531361799 |
Product resources
Documentation
Manuals, technical information and catalogues for Nomada 12V 105Ah.
Product documents & support
Brand catalogue
Need help specifying a complete system?
