TBS Electronics · Omnicharge Battery Chargers
Omnicharge Solar MPPT 20A – 70A
Smart, ultra-fast MPPT solar charge controllers for 12/24/36/48V PV systems and all common battery types.
Ask our team about compatibility, current pricing and availability.
Ask about this product on WhatsApp ↗
View documentation 8 files & links ↓Key features
- Models OCS100-20, 100-30, 100-50, 150-60 and 250-70
- Smart, ultra-fast Maximum Power Point Tracking
- PV array power from 260 Wp up to 3.6 kWp
- Battery system voltages of 12V, 24V, 36V and 48V
- Very low self-consumption — excellent output at sunrise & low light
- High-resolution power control circuits
- Battery temperature sensor included on OCS150-60 and 250-70
- Fully programmable — easy to install with clear instructions
Specifications
| Type | MPPT solar charge controller |
|---|---|
| Battery voltage | 12 / 24 / 36 / 48 V |
| PV array power | 260 Wp – 3.6 kWp |
| Output current | 20 – 70 A (model dependent) |
| Temp sensor | Included on 150-60 & 250-70 |
| Art. numbers | 5024200 / 5024300 / 5024500 / 5024630 / 5024770 |
Product resources
Documentation
Manuals, technical information and catalogues for Omnicharge Solar MPPT 20A – 70A.
