TBS Electronics · Omnicharge Battery Chargers
Omnicharge2 20A – 60A (12/24V)
Three-output programmable chargers with a clear backlit display showing charge progress, voltage and current per output.
Ask our team about compatibility, current pricing and availability.
Ask about this product on WhatsApp ↗
View documentation 6 files & links ↓Key features
- Models OC12-40, OC12-60, OC24-20 and OC24-30
- Three individually programmable, isolated outputs
- Charge different battery types & sizes from one charger
- AGM, GEL, Flooded and Lithium programs (with/without float)
- Temperature-compensated charging, editable voltage/current levels
- 'Night Mode' stops the fans when silence is required
- Setup & readout via Dashboard Mobile (Bluetooth) or Dashboard for Windows
- Temperature sensor included — easy to install
- CE marked — 24 month warranty
Specifications
| AC input | 100–260 Vac / 47–63 Hz, PF ≥ 0.95 |
|---|---|
| Outputs | 3 isolated, individually programmable |
| Charge programs | AGM, GEL, Flooded, Lithium + custom |
| Display | Backlit, per-output voltage & current |
| Communication | Bluetooth / USB / RS232 (Dashboard) |
| Extras | Night Mode, temperature sensor included |
| Warranty | 24 months |
Product resources
Documentation
Manuals, technical information and catalogues for Omnicharge2 20A – 60A (12/24V).
Product documents & support
Brand catalogue
