Super B · Nomia High-Capacity
Nomia 12V 340Ah SIL
340 Ah lithium iron phosphate battery for high-capacity energy storage systems. SIL version with cross-monitoring and model-specific software limits.
Ask our team about compatibility, current pricing and availability.
Ask about this product on WhatsApp ↗
View documentation 8 files & links ↓Key features
- High-capacity LiFePO₄ energy storage
- Model-specific charging limits and protection requirements
- CAN-based system integration
Specifications
| Nominal capacity | 340 Ah |
|---|---|
| Nominal voltage | 12.8 V |
| Energy | 4352 Wh |
| Chemistry | LiFePO₄ |
| Dimensions (L × W × H) | 417 × 227 × 314 mm |
| Weight | 33 kg |
| Charge method | CCCV |
| Charge voltage | 14.2 V |
| Maximum charge current | 300 A — observe the datasheet temperature limits |
| Continuous discharge current | 300 A |
| Pulse discharge current | 900 A (30 seconds) |
| Ingress protection | IP50 |
| EAN | 8718531362512 |
