Ratio Electric · Power Solutions
IPDU Per Inlet Monitored (Light)
Light metered intelligent PDU with remote internet access per inlet (no SNMP controller).
Ask our team about compatibility, current pricing and availability.
Ask about this product on WhatsApp ↗
View documentation 2 files & links ↓Key features
- Basic and intelligent power distribution units for marinas, workshops and events
- Metered and individually switchable outlets on intelligent models
- Industrial CEE (IEC 60309) and Schuko outlet configurations
- Cords, plugs and components to build a complete distribution chain
- Weather-resistant enclosures for exposed dockside positions
Specifications
| Model selection | Ratings and options below apply to the identified manufacturer article. |
|---|---|
| PIML-V-36-24IEX | IPDU PIML 1x16A, 24xIEX, H05VV-F3G1.5mm² 3M CEE plug · Max. Current (A): 16 · Rated Voltage / Phase: 230V / 1~ · Outlets: 24x IEX · Input Plug: CEE 3-pins · Cable Length (M): 3 meter · Length Housing (Mm): 1042 · Remarks: H05VV-F3G1,5mm2 |
| PIML-V-72-24IEX | IPDU PIML 1x32A, 24xIEX, H07RN-F3G4mm² 3M CEE plug · Max. Current (A): 32 · Rated Voltage / Phase: 230V / 1~ · Outlets: 24x IEX · Input Plug: CEE 3-pins · Cable Length (M): 3 meter · Length Housing (Mm): 1262 · Remarks: H07RN-F3G4mm2 |
| PIML-V-11-24IEX | IPDU PIML 3x16A, 24xIEX, H07RN-F5G2,5mm² 3M CEE plug · Max. Current (A): 16 · Rated Voltage / Phase: 400V / 3~ · Outlets: 24x IEX · Input Plug: CEE 5-pins · Cable Length (M): 3 meter · Length Housing (Mm): 1362 · Remarks: H07RN-F5G2,5mm² |
| PIML-V-22-24IEX | IPDU PIML 3x32A, 24xIEX, H07RN-F5G4mm² 3M CEE plug · Max. Current (A): 32 · Rated Voltage / Phase: 400V / 3~ · Outlets: 24x IEX · Input Plug: CEE 5-pins · Cable Length (M): 3 meter · Length Housing (Mm): 1662 · Remarks: H07RN-F5G4mm² |
| PIML-V-36-36IEX | IPDU PIML 1x16A, 36xIEX, H05VV-F3G1.5mm² 3M CEE plug · Max. Current (A): 16 · Rated Voltage / Phase: 230V / 1~ · Outlets: 36x IEX · Input Plug: CEE 3-pins · Cable Length (M): 3 meter · Length Housing (Mm): 1412 · Remarks: H05VV-F3G1,5mm2 |
| PIML-V-72-36IEX | IPDU PIML 1x32A, 36xIEX, H07RN-F3G4mm² 3M CEE plug · Max. Current (A): 32 · Rated Voltage / Phase: 230V / 1~ · Outlets: 36x IEX · Input Plug: CEE 3-pins · Cable Length (M): 3 meter · Length Housing (Mm): 1612 · Remarks: H07RN-F3G4mm2 |
| PIML-V-11-36IEX | IPDU PIML 3x16A, 36xIEX, H07RN-F5G2,5mm² 3M CEE plug · Max. Current (A): 16 · Rated Voltage / Phase: 400V / 3~ · Outlets: 36x IEX · Input Plug: CEE 5-pins · Cable Length (M): 3 meter · Length Housing (Mm): 1512 · Remarks: H07RN-F5G2,5mm² |
| PIML-V-22-36IEX | IPDU PIML 3x32A, 36xIEX, H07RN-F5G4mm² 3M CEE plug · Max. Current (A): 32 · Rated Voltage / Phase: 400V / 3~ · Outlets: 36x IEX · Input Plug: CEE 5-pins · Cable Length (M): 3 meter · Length Housing (Mm): 1812 · Remarks: H07RN-F5G4mm² |
Product resources
Documentation
Manuals, technical information and catalogues for IPDU Per Inlet Monitored (Light).
